Voltage Sensor ± 1 Volts

$128.00 excl. GST

This sensor will give an accurate reading of voltage in any circuit configuration with a supply voltage of less than 20Volts.

Cat. No. 44S1859 Category:

Description

This sensor will give an accurate reading of voltage in any circuit configuration with a supply voltage of less than 20Volts.Logger compatibility: ScienceScope Type 3 (See ScienceScope website for details)±1 volts   resolution 0.002 voltsMaximum recording frequency with Datadisc is 61 microsecondsThe four Voltage sensors allow all possible types of investigation to be carried out.Voltage and current sensors can be used together anywhere in a circuit with a supply voltage of up to 24 volts with no interference between sensors. All work from DC to 10KHz.Derived Sensors:PowerEnergyCurrent (if circuit resistance is known)RMS VoltageResistance  (requires a current sensor)
Typical Investigations:
AC and DC currentsCurrent and voltage in a diodeCurrent and voltage in a filament bulbCurrent and voltage in a LDRCurrent and voltage in a resistorCurrent and voltage in a thermistorEnergy consumptionRelationship between power, voltage and currentResistance in a circuitInduced e.m.f.
